4x2 Drive Tipper Dump Truck Wheel Mini Dumper 2 - 15t Load In Guatemala

4x2 Drive Tipper Dump Truck Wheel Mini Dumper 2 - 15t Load In Guatemala
4x2 Drive Tipper Dump Truck Wheel Mini Dumper 2 - 15t Load In Guatemala 4x2 Drive Tipper Dump Truck Wheel Mini Dumper 2 - 15t Load In Guatemala 4x2 Drive Tipper Dump Truck Wheel Mini Dumper 2 - 15t Load In Guatemala

Large Image :  4x2 Drive Tipper Dump Truck Wheel Mini Dumper 2 - 15t Load In Guatemala

Product Details:
Place of Origin: Shandong Province, China
Brand Name: Genron
Certification: CCC,CQC,CNAS
Model Number: GV-MT-4
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: USD 7000-9000
Packaging Details: naked packing
Delivery Time: 5-20 work days
Payment Terms: T/T
Supply Ability: 50000 pcs per month

4x2 Drive Tipper Dump Truck Wheel Mini Dumper 2 - 15t Load In Guatemala

Description
Product Model: 178T Fuel Type: Diesel
Engine Type: YUNNEI490 Engine Power: 46KW(63HP)
Gearbox Model: 530(Twelve Gears High And Low) Real Axle: DF1069
Front Axle: SL178 Braking System: Automatically Air-cut Brake
High Light:

4x2 Drive Tipper Dump Truck

,

15t Tipper Dump Truck

,

4x2 Wheel Mini Dumper

4x2 Drive Wheel Mini Dumper 2 - 15t Load Dump Truck in Guatemala



4x2 Drive Tipper Dump Truck Wheel Mini Dumper 2 - 15t Load In Guatemala 0



Product Specification:



Name
5 ton 8 ton 10 ton underground mining truck with four wheel drive truck  from Genron Vehicle
product model
178T
Fuel type
diesel
engine type
YUNNEI490
engine power
46KW(63HP)
Gearbox model
530(Twelve gears high and low)
Real axle
DF1069
Front axle
SL178
Braking system
automatically air-cut brake
Rear wheelbase
1630mm
Front wheelbase
1630mm
Axle distance
2400mm
Frame
Main beam:Hight120mm*Wide60mm*Thickness8mm,Bottom beam:Hight80mm*Wide60mm*Thickness6mm
Unloading method
Dump ,800mm Double tops
Tire type of Front
700-16Mine tire
Tire type of Behind
700-16Mine tire(Double tire)
Overall size
Length 4900mm*Wide 1630mm*Hight1400mm
Box size
Length 3100mm*Wide 1600mm*Hight500mm
Backplate30+20 Removable
Thickness of container plate
Bottom10mm
Side5mm
Steering Gear Box
hydraulic power assisted
Leaf Spring
13pcs*Wide70mm*Thickness12mm
container volume
(m³)
2.2
Loading Capacity
5 tons
Tail gas treatment
exhaust purifier



Details:

4x2 Drive Tipper Dump Truck Wheel Mini Dumper 2 - 15t Load In Guatemala 1



Vehicle characteristics Reasonable design:



the whole vehicle design combines the characteristics of underground vehicles, compact structure,

reasonable layout. Length 4900mm*width 1630mm*height 1400mm. cargo compartment volume 2.2³.

It is suitable for use in 2.5*2.5 and above tunnels. Size can be customized according to requirements.



4x2 Drive Tipper Dump Truck Wheel Mini Dumper 2 - 15t Load In Guatemala 2



Strong load capacity:

the vehicle adopts the design concept of large horse-drawn car, rated load of 5 tons. Maximum load
capacity is 6 tons. It adopts Q345B manganese steel plate with high quality characteristics to make
closed box-shaped section steel frame, with solid structure, high torsional and impact strength,
large steel degree, strong and durable. The specially designed suspension system made of 60 silicon
di-manganese and the large diameter mining tires ensure its super load capacity. The load capacity
is 1.5 times that of ordinary road vehicles.

4x2 Drive Tipper Dump Truck Wheel Mini Dumper 2 - 15t Load In Guatemala 3

Good passability:

The compact structure of the 178T mine dump truck is suitable for flexible operation in the narrow space
of the shaft ramp by the special design of the cab (front part), suspension, frame, cargo compartment
and lifting mechanism, with compact structure and small turning radius, which is extremely flexible.

4x2 Drive Tipper Dump Truck Wheel Mini Dumper 2 - 15t Load In Guatemala 4

High safety factor:

According to the characteristics of humid air, insufficient light and slippery road, the vehicle lamps and
electrical components are improved, waterproof and moisture-proof performance is enhanced,
special anti-skid tires are selected, with strong ability to cross obstacles and good safety.

4x2 Drive Tipper Dump Truck Wheel Mini Dumper 2 - 15t Load In Guatemala 5
Good adaptability:

Timely can be applied to a variety of high-altitude, watery, high temperature and other complex working conditions.
At present, it has been applied to Tibet 4800m high altitude area without failure rate.



Package & Factory:



4x2 Drive Tipper Dump Truck Wheel Mini Dumper 2 - 15t Load In Guatemala 6



4x2 Drive Tipper Dump Truck Wheel Mini Dumper 2 - 15t Load In Guatemala 7



Marketing & Service:

Our petroleum tanker trailer / fuel tanker semi-trailer were exported to Saudi Arabia, Algeria ,Senegal,
Botswana, Mozambique, Zambia,Malawi,Uganda ,Tanzania,Malaysia, Philippines,Vietnam,,Myanmar,
Russia,Uzbekistan and Pakistan in the past 15 years.

4x2 Drive Tipper Dump Truck Wheel Mini Dumper 2 - 15t Load In Guatemala 8

Pre-sales service:

* Inquiry and consulting support.
* Sample testing support.
* Pick you from airport together to visit factory production line ,and make sure your safety in China.

After sale service:

* We will often go abroad to check our products ,and enlarge our office out of China.
* Engineers available to service machinery overseas.
* 16 Engineers always service for exporting business .

4x2 Drive Tipper Dump Truck Wheel Mini Dumper 2 - 15t Load In Guatemala 9
