Product Details:
|
| Product Name: | Genron Extendable Flatbed Semi Trailer For Sale To Botswana | Brand Name: | Genron Vehicle |
|---|---|---|---|
| Usage: | Semi Trailer | Material: | Steel |
| Size: | 12500mm*2500mm*1550mm | Max Loading Capacity: | 90Tons |
| Twist Lock: | 8 Unite/12 Unite/without | Leaf Spring: | 90mm(W)*16mm*10layers |
| Tare Weight: | 7 Tons | Origine Place: | Shandong,China |
| Axle: | 13T/16T Fuwa Or BPW Brand | ||
| High Light: | genron flatbed semi trailer,genron semi truck flatbed trailer,extendable semi truck flatbed trailer |
||
Genron extendable 3 axles flatbed semi trailer for sale to Botswana
Discription of product:
Factory high quality extendable flatbed trailer long cargo flatbed deck semi traielr
This flatbed semi trailer is a kind of semi-trailer that has a super low cargo platform, the platform is also called drop-deck. Mainly
specialized for transportation of crawler crane, excavator, crawler loader, bulldozer, railroad equipment, and other crawlers/tires equipment.
Benefit from the low bed design, the trailer has high trafficability to go through bridge arc and tunnel, and lowers COG(center of gravity) of cargo.The trailer body has a drop-deck which is lower than the front gooseneck and the rear wheel-set, due to the drop deck design, it always comes with a gooseneck, so it is also called low bed semi-trailer.
Specification of the trailer:
| Extension Flatbed Semi Trailer Specifications | |
|---|---|
| Specifications | |
| Dimension: | 13000*2550*1550mm (Customized) |
| Load Capacity: | 60Tons or can be customed etc |
| Founction: | Bulk Cargo or Transport 1*40ft container, 2*20ft container |
| Chassis | |
| Main Beam: |
Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes. |
| Frame Floor | The Thickness is 3mm pattern |
| Parts | |
| Axle: | FUWA or BPW, 13T or 16T |
| Suspension: | Mechanical or Air Suspension |
| King Pin: | 2'' or 3.5'' Jost |
| Landing Gear: | 28T STANDARD double speed |
| Rim: | 9.0R22.5 the quanlity according to your requirements |
| Tire: | 12R22.5(Option:11.00-20, 12.00-20) |
| Brake System: | WABCO, ABS Optional |
| Leaf Spring: | 90mm(W)*16mm(T)*10 Layer (Option:90/16/10;100/16/10) |
| Electrial System: | 24V; 7 ways receptacle; LED lamps |
| Accessories: | One tool box, one spare tire carrier |
| Painting: | Complete chassis sand blasting to clean rust,1 coat of anti-corrosive prime,2coats of final paints |
| Colour and Marking: | meet customer’s requirement |
Production line:
After fully realizing the road construction in defferent countries,Genorn Vehicle adopts the advanced design concept.To make sure the service life long ,the spare parts we used are from China /World famous brand.
Genorn extendable flatbed semi trailer
Lifting function optional :hydraulic lifting suspension be able to adjust height
Suspension can be mechanical normal suspension ,bogie cantilever suspension ,air bag suspension or hydraulic steering suspension.
Length or width can be telescopic extension or hydraulic cylinder extension.
Can be together will front towing dolly for over heavy duty cargo transporting.
We have single axle,2-5 axles and 3 lines 6 axles ,we also can design and produce the same type lowbed semi trailer
Shipping itemes:
Roro Ship or Bulk Cargo Ship
This package for roro ship or bulk cargo ship delivery.
If your order is more than three units or 6 or 9 can be package like this .
Pls check your destination port if there is bulk cargo port near to your city.
Disadvantage : the bulk cargo fee is a little expensive than the container fee.
Advantage: no need to weld ,can work directly after you receive them.
By Container
If your order is two units low bed trailer or double pieces ,you can choose put two units into one 40HQ container for shipping ,
we will design one tail part connected by strong bolts ,after you received the trailer you should connecting them by strong bolts
first and then welding the two parts together ,It's a easy work for welding man.
Customer photo show:
Welcome you and your friend to visit our plant and our company.If you need ,plz let me know.
I am Zoe (whatsapp :+86-18363983168)
About Genorn Vehicle:
Qingdao Genron International Trade Co., Ltd Main Business is Exporting all kinds of trailers, trailer parts and Man-hand Welding Machinery, Automatic Welding machinery, Trailer Production Line Etc. We have our own factory which produce trailers for more than 15 years, we can help you export other machinery and trucks.
China as a global manufacturing center, Genron want to be your first service center in china. Genron composed by and efficient,experienced and reliable team, has low costs, competitively priced services and reliability reputation. We have ability to reduce risk and facilitate procurement in the mirror trade business averment through our comprehensive system and reliable factories.
For the price ,we cannot say anything For the quality,we only do the best.
