Product Details:
|
| Material: | Steel | Suspension: | Mechanical Suspension / Americon Type |
|---|---|---|---|
| King Pin: | JOST 2.00 Or 3.5 Inch Bolt-in King Pin | Landing Gear: | JOST (D200T）or CHINA BRAND 28T |
| Axle: | 2 Axles, FUWA/HUAJING Brand 16tons Per Axles | Color: | Customized |
| Dimension: | 11280*2495*3970mm ( Outside) 10500*2300*1700mm (work Space ) | Loading Capacity: | More Than 50 T |
| Tire: | 12.00R22.5/315 80R22.5/11.00R20 /12.00R20 Brand Can Be Optional |
2 Axles 50T Dump Semi Truck Trailer For Delivery Sands Export To Kazakhstan, Uzbekistan, Malaysia ,and so on.
| Main Dimensions | |
| Dimension |
11280*2495*3970mm ( outside) 10500*2300*1700mm (work space ) |
| Tare weight | About 15600KGS |
| Total Volume(m3) | 37 m³ or less than 80tons |
| Side wall thickness(mm) | 6mm Q235 steel |
| Bottom plate thickness(mm) | 8mm /Q235 steel |
| Lifting system | Full set of Hyva (FC214-5-07130) Hydraulic Lifting Cylinder |
| Chassis | |
| Main Beams | Height:500mm, upper plate is 16mm,middle is 8mm(double+three plate),down plate is 18mm,material is Q345B steel |
| Axle | 2 axles, FUWA/HUAJING brand 16tons per axles |
| Landing Gear | JOST (D200T)or CHINA BRAND 28T |
| King Pin | JOST 2.00 or 3.5 inch bolt-in king pin |
| Suspension | Mechanical suspension / Americon Type |
| Leaf Spring | 90(W)mm*13(Thickness)mm*10 Layer |
| Pneumatic Braking System | WABCO RE 6 relay valve; Spring brake chamber; one piece of 45L air tanks. |
| Rim | 9.00-22.5/8.00-20/8.5-20 China Brand |
| Tire | /12.00R22.5/315 80R22.5/11.00R20 /12.00R20 Brand can be Optional |
| ABS | Optional |
| Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
| Accessories | One standard tool box |
| Shipping Terms | By Bulk Cargo or roro, the trailer size can be design according to your special requirement , the tractor truck can be choose 6*4 model . |
Advantages Of 2 Axles 50T Dump Semi Truck Trailer For Delivery Sands
1. It is suitable for the transportation of bulk goods such as coal, ore and construction materials. Dump semi-trailer can be divided into two categories according to their uses: one is heavy-duty and super heavy-duty dump trucks for off-road transportation, mainly responsible for large-scale mining, engineering and other transportation tasks, usually used together with excavators. The other type of light and medium-sized ordinary dump truck for highway transportation mainly undertakes the transportation of sand, soil, coal and other loose goods, which is usually used together with loaders.
2. The carriage adopts rollover and backward dump mode, which can effectively improve the transportation efficiency of bulk goods transported by the loader.
3. The frame and the longitudinal beam of the carriage are welded with high-quality manganese plate, and there are dustpan and rectangular box. It has high strength, strong lifting force, good rigidity and toughness, strong bearing capacity and no permanent deformation.
4. Hyva hydraulic jacking cylinder is selected, which has stable lifting performance. The longitudinal beam is made of automatic submerged arc welding. The axle and steel spring are accurately assembled by assembly machine.
5. It can be designed separately according to the different needs of customers, or tell us that the medium of the goods you carry is different. We will design the corresponding model for you to meet the personalized needs of customers.
Qingdao Genron International Trade Co., Ltd Main Business is Exporting all kinds of trailers, trailer parts and Man-hand Welding Machinery, Automatic Welding machinery, Trailer Production Line Etc. We have our own factory which produce trailers for more than 15 years, Our CEO Mrs. Zhao have 11 years export Construction and trailer trucks experiences; She have visited more than 22 countries for checking trailer truck markets. We can supply the right product in shortest ways and cheapest value.
The strong advantage of Genron company with other trading company is we have our own professional technical design team.If you uncertain your products or your own design,we can go to visit you ,help you checking and analysis your market and gave you special and right design according to your country situation. As our more than 11 years overseas visited record and exporting business experience focus on the trailer and truck filed ,we can gave you the right product in very short way.
Why do you choose Genron?
11 years overseas experience :
As our more than 11 years overseas produce and exporting business experience focus on the trailer and truck filed ,We used nine years visited
On Ghana, Burkina faso, Cameroon, Nigeria, Mozambique, Zambia ,Tanzania ,Kenya, Malaysia ,Indonesia ,Philippine, Vietnam ,LAOS , Mayanmar, Algeria, Dubai.
Mirror Trading :
we will gave you the best price and quality product. Because we hope our cooperation like mirror ,Customer as mirror ,one side is factory ,inside is Genron,
We Minimize all loses that may arise from the producers .We respond to the demands and requirements of the companies , we work with in the most effective way and as soon as possible.
Professional Technical Team:
The strong advantage of Genron compare with other trading company and company is we have our own professional design team: One engineer Mr.Fanming Bu (working for CIMC company five years, design trailer and production line six years),Five technical person: Mr.Wenming Zhao(design tanker trailer for 11 years),Mr. Xianzhen Zhao(design welding machinery four years), Mr.Haifeng Liu(design trailer axles four years). Mr.Zuoliang Yang( design tipper trailer six years).Mr.Jihe Cao(Design tanker trailer five years).
