45ft Container Q235 Skeleton Semi Trailer Mechanical / Air / Bogie Suspension

Certification
China Qingdao Genron International Trade Co., Ltd. certification
China Qingdao Genron International Trade Co., Ltd. certification
I'm Online Chat Now

45ft Container Q235 Skeleton Semi Trailer Mechanical / Air / Bogie Suspension

45ft Container Q235 Skeleton Semi Trailer Mechanical / Air / Bogie Suspension
45ft Container Q235 Skeleton Semi Trailer Mechanical / Air / Bogie Suspension 45ft Container Q235 Skeleton Semi Trailer Mechanical / Air / Bogie Suspension

Large Image :  45ft Container Q235 Skeleton Semi Trailer Mechanical / Air / Bogie Suspension

Product Details:
Place of Origin: China
Brand Name: Genron
Certification: CCC CE
Model Number: GV03034
Payment & Shipping Terms:
Minimum Order Quantity: 3 unit
Price: USD 9000 - 15000 per unit
Packaging Details: By bulk cargo shipping or 40ft container shipping
Delivery Time: 20-30 work days
Payment Terms: T/T
Supply Ability: 80 units per morth

45ft Container Q235 Skeleton Semi Trailer Mechanical / Air / Bogie Suspension

Description
Size: 13950mm*2480mm*1550mm Max Loading: 45-60 Tons
Material: Q235 Steel Suspension: Mechanical / Air / Bogie Suspension
Axle: 13T FUWA Brand / GV Brand Tire: 12.00R22.5 / 315/80R22.5
Rim: 9.00-22.5 Landing Leg: Chinese 28T Double Speed
High Light:

Container Q235 Skeleton Semi Trailer

,

45ft Skeleton Semi Trailer

,

45ft skeletal semi trailer

Introduction of 3 alxes Skeleton semi trailer



Container Semitrailer A semi-trailer with container structure for loading.Mainly used for ships, ports, routes, highways, transit stations, Bridges, tunnels, multimodal transport supporting the logistics system



45ft Container Q235 Skeleton Semi Trailer Mechanical / Air / Bogie Suspension 0



Advantage of 3 alxes Skeleton semi trailer



1. It is specially used for the transportation of various containers.It can be used repeatedly for a long time and has sufficient strength.



2, the use of container transport goods, can be directly in the shipper's warehouse loading, shipped to the consignee's warehouse unloading, midway to change the vehicle, ship, do not need to take out the goods from the box for replacement.



3, can be fast loading and unloading, and can be directly and conveniently changed from one means of transport to another means of transport.



4. It is easy to fill and unload the goods to meet the individual needs of customers.According to customer needs to ensure the tooling, quality and stability, reliable performance.



Configuration of 3 alxes Skeleton semi trailer



45ft Container Q235 Skeleton Semi Trailer Mechanical / Air / Bogie Suspension 1



Gross Weight About 6 tons
Outer side dimension (mm) 13950mm*2480mm*1550mm (The specific height is determined by height of coupling face)
Loading Capacity (Ton) ≤ 40 T
Axle 2/3pcs 13T FUWA Brand or GV brand Axles 16T Widen the brake pads
Tire 12.00R22.5 Linglong Brand 3 axles:12 pcs 2 axles:8 pcs
Rim 9.00-22.5 3 axles:12 pcs 2 axles:8 pcs
Suspension All mechanical suspension or front axle air suspension
Spring leaf 90(W)mm*13(Thickness)mm*10 Layer
King pin JOST brand 3.5inch bolts type or Welding type
Support leg JOST brand D200T or China brand 28Tons (Double speed)
Main beam Height: 500mm
Brake chamber WABCO RE 6 relay valve; 2* T30/30+T30 Spring brake chamber
Twist Locks 14 pcs
Valve WABCO valve
Light LED light
Voltage 24V
Receptacle 7 ways (7 wire harness)
Fender Overall wavy shape
Spare wheel carrier 2 pcs, spare tire is not included
Tool box One piece, 1.5m×0.5m×0.5m (on the right side of the semi trailer)
Painting Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
Shipping Terms: Transport by bulk cargo carrier. Customers need a large number of every four semi - trailer lined up together for transport, Outside dimension for transport: 15300mm*2500mm*4500mm




We are one of the manufacture for semi-trailers till 20 years ;our production quantity is about 7200units , do exporting trailers for ten years already ,So Genron brand will be your trusted brand in China market.



45ft Container Q235 Skeleton Semi Trailer Mechanical / Air / Bogie Suspension 2



Skeleton semi trailer is mainly used for ships, ports, routes, highways, transit stations, Bridges, tunnels, multimodal transport and supporting logistics systems.



Productive details of 3 alxes Skeleton semi trailer



45ft Container Q235 Skeleton Semi Trailer Mechanical / Air / Bogie Suspension 3



45ft Container Q235 Skeleton Semi Trailer Mechanical / Air / Bogie Suspension 4



45ft Container Q235 Skeleton Semi Trailer Mechanical / Air / Bogie Suspension 5



45ft Container Q235 Skeleton Semi Trailer Mechanical / Air / Bogie Suspension 6



45ft Container Q235 Skeleton Semi Trailer Mechanical / Air / Bogie Suspension 7



Mode transport of 3 alxes Skeleton semi trailer



This package for roro ship or bulk cargo ship delivery. If your order it, can be package like this.



Pls check your destination port if there is bulk cargo port near to your city.



Advantage: no need welding ,can be work directly after you received.



45ft Container Q235 Skeleton Semi Trailer Mechanical / Air / Bogie Suspension 8



Introduction of our company



45ft Container Q235 Skeleton Semi Trailer Mechanical / Air / Bogie Suspension 9



45ft Container Q235 Skeleton Semi Trailer Mechanical / Air / Bogie Suspension 10



45ft Container Q235 Skeleton Semi Trailer Mechanical / Air / Bogie Suspension 11



45ft Container Q235 Skeleton Semi Trailer Mechanical / Air / Bogie Suspension 12
